CXL 2.0 - Aglx CXL2.0 - Premium CXL 1.1 - Ultra

Overview

Mobiveil’s CXL 2.0 – AglxTM Accelerator platform is a PCIe Gen5 add-in card with latest Intel’s Agilex I series FPGA. It supports any third party’s latest high performance CXL Controller IP that is highly configurable for a number of High-Performance Applications, such as Accelerators, Artificial Intelligence and Machine Learning.
  • Ideal platform to run CXL applications that maintains memory coherancy between devices, allowing resource sharing for higher performance
  • Suitable for emerging data processing applications in AI, media, image and language processing
  • Genomics
  • Video Processing / Transcoding
  • Financial Computing
  • Database Search and Analytics
  • Machine Learning Suite for Inference (Tensorflow, Caffe and MXNet)
  • Neural Network Inference for Image Classification
  • RoHS Compliance
  • PCIe Gen5 1.0 Compliance
  • CE/FCC to be certified
  • CXL-AglxTM reference platform
  • Software drivers
  • User guide
CXL-Aglx 2.0 block diagram
Interface specifications
• PCIe Gen5 x 16 at edge fingers • PCIe Gen5 x 8 at PCIe Edge Connector • Two PCIe Gen5 x 8 at CXL IO connector (CXL Host slot)
Memory specifications
• Supports upto 64GB of DDR4 memory for FPGA Logic and Processor subsystem
Environmental specifications
• Operating temperature : 0 deg C to 55deg C • Storage Temperature : -20deg C to +70deg C • Humidity : 10% to 90% non-condensing, Airflow 400LFM
Mechanical specifications
• PCIe Full length, Full height form factor 312mm x 111mm
Power specifications
• Typical power consumption : Less than 100W • Support for Auxiliary Power feed
FPGA
• Intel Agilex I series
Standard compliance
• PCIe Base specifications 5.0 • CXL 1.1, CXL 2.0 (TBD)

Get the Detailed Product Brief here

Download

Overview

Mobiveil’s CXL2.0 – Premium Accelerator platform is a PCIe Gen5 add-in card with latest Xilinx’s FPGA Versal Premium. It supports any third party’s latest high performance CXL Controller IP that is highly configurable for a number of High-Performance Applications, such as Accelerators, Artificial Intelligence and Machine Learning.

  • CXL2.0-PremiumTM is an ideal Platform to leverage the capabilities of high performance CXL protocol.
  • Emerging data-processing applications in AI, media, image and language processing, encryption.
  • It supports CXL.io, CXL.mem and CXL.cache layers that are highly efficient and configurable for a low-latency coherent path.
  • CXL2.0-PremiumTM maintains memory coherency between the devices, allowing resource sharing for higher performance, reduced software stack complexity and lower overall system cost.
  • Genomics
  • Video Processing / Transcoding
  • Financial Computing
  • Database Search and Analytics
  • Machine Learning Suite for Inference (Tensorflow, Caffe and MXNet)
  • Neural Network Inference for Image Classification
  • RoHS Compliance
  • PCIe Gen5 1.0 Compliance
  • CE/FCC to be certified
  • CXL2.0-PremiumTM reference platform
  • Software drivers
  • User guide
CXL2.0 Premium block diagram
Interface specifications
• PCIe Gen5 x 4 at edge fingers • PCIe Gen5 x 4 at PCIe Connector (CXL - Host Slot)
Memory specifications
• Supports upto 16GB of DDR4 memory for FPGA Logic • Supports upto 16GB of DDR4 memory for Processor subsystem
Environmental specifications
• Operating temperature : 0 deg C to 55deg C • Storage Temperature : -20deg C to +70deg C • Humidity : 10% to 90% non-condensing, Airflow 400LFM
Mechanical specifications
• PCIe Full length, Full height form factor 312mm x 111mm
Power specifications
• Typical power consumption : Less than 75W • Support for Auxiliary Power feed
FPGA
• Xilinx Versal Premium
Standard compliance
• PCIe Base specifications 5.0

Get the Detailed Product Brief here

Download

Overview

Mobiveil’s CXL 1.1 – UltraTM Accelerator platform is a PCIe add-in card with Xilinx’s Zynq Ultrascale+ FPGA. It supports any third party’s latest high performance CXL Controller IP that is highly configurable for a number of High-Performance Applications, such as Accelerators, Artificial Intelligence and Machine Learning.

  • CXL1.1-UltraTM is an ideal Platform to leverage the capabilities of high performance CXL protocol.
  • Emerging data-processing applications in AI, media, image and language processing, encryption.
  • CXL1.1-UltraTM maintains memory coherency between the devices, allowing resource sharing for higher performance, reduced software stack complexity and lower overall system cost.
  • CXL.mem and CXL.cache layers that are highly efficient and configurable for a low-latency coherent path.
  • Accelerators for AI, Machine Learning
  • IOT analytics
  • Image and language processing
  • RoHS Compliance
  • PCIe Gen4 Compliance
  • CE/FCC to be certified
  • CXL1.1-UltraTM reference platform
  • Software drivers
  • User guide
CXL1.1 Ultra block diagram
Interface specifications
• PCIe Gen4 x 8 at edge fingers • PCIe Gen4 x 8 at PCIe Connector (CXL Host port)
Memory specifications
• Supports upto 16GB of DDR4 memory for FPGA Logic • Supports upto 16GB of DDR4 memory for Processor subsystem
Environmental specifications
• Operating temperature : 0 deg C to 55deg C • Storage Temperature : -20deg C to +70deg C • Humidity : 10% to 90% non-condensing, Airflow 400LFM
Mechanical specifications
• PCIe Full length, Full height form factor 312mm x 111mm
Power specifications
• Typical power consumption : Less than 75W • Support for Auxiliary Power feed
FPGA
• Xilinx ZynQ Ultrascale+ FPGA
Standard compliance
• PCIe Base specifications 4.0

Get the Detailed Product Brief here

Download
